Watts Series 100XL Temperature and Pressure Relief Valves
Series 100XL Temperature and Pressure Relief Valves are used in water heater and hot water storage tank applications to provide automatic temperature and pressure protection to hot water supply tanks and hot water heaters up to 105,000 BTU/hr. They feature a bronze body with NPT male inlet and NPT female outlet connections, unique thermostat with special thermo-bonded coating, and a test lever. Model 100XL-8 is also available with 8 in. (200mm) extension thermostat. Series 100XL is ASME rated and CSA listed. Temperature Relief: 210°F (99°C), Pressure Relief Range: 75 to 150psi (5.2 to 10.3 bar), Standard Pressure Settings: 75, 100, 125, or 150psi (5.27, 7.03, 8.79, or 10.55 bar).
Series 1L, 1XL Size 1⁄2" 10L, 100XL Size 3⁄4"
A.S.M.E. Rated*, CSA Listed
Features a unique thermostat with special thermo-bonded coating
1L & 1XL – Bronze body 10L & 100XL – Brass body
Stainless steel spring
Thermostat is accurate and proven. Exclusively designed and manufactured by Watts
